Petrochemical Applications

Petrochemical materials

Product Info

Prod. Grade ASTM A179,A210 A213, A334, A333, A335
Prod. Equivalent DIN : 17175, 17173, 17174

Product Description

Haesung ST provides a full range of seamless & welded  tubes and pipes for  petrochemical and chemical industries where large diameter pipes and alloy steel are necessary to withstand extreme temperatures and high-pressure environments. These are primarily saved for the most problematic areas where extremely high temperatures or very corrosive chemicals are present.

Product Item

  • ASTM A179 : Seamless cold drawn low carbon steel tubes for tubular heat exchanger & condenser tubing
  • ASTM A192 : Specification for seamless carbon steel boiler tubes for high pressure service
  • ASTM A210 : Seamless medium carbon steel boiler and super heater tubes
  • ASTM A213 : T2, T5, T5b, T5c, T9, T11, T12, T17, T21, T22, T23, T24, T91, T92
  • ASTM A334 : Gr.1,Gr .3, Gr.6, Gr.8, Gr.9, Gr.11
  • ASTM A333 : Gr.1, Gr.3, Gr.4, Gr.6, Gr.7, Gr.9, Gr.10, Gr.11
  • ASTM A335 : Grade P1, P2, P5, P5b, P5c, P9, P11, P12, P15, P21, P22, P23

Product range

  • Outside diameter : 12.7mm ~ 406.4mm
  • Wall thickness : 0.8mm~40.49mm
  • Length : 24,000mm(max)
  • Product capacity per month : 1,000 M.T

Related standards

  • ASME / ASTM : SA/A213, SA/A334, SA/A333, SA/A335
  • JIS  : G3462, G3460, G3464, G3458
  • DIN : 17175, 17173, 17174
  • BS  :  3059, 3603, 3604

Applications

  • Petrochemical plants: olefins, fertilizers, aromatics and others
